Blackmagic SDI to HDMI 4K
Blackmagic Design SDI to HDMI 4K Mini Converter (BMD-CONVMBSH4K)
blackmagic_mini_converter_sdi_hdmi_4k / BMD-CONVMBSH4K
Shipping
Calculate Shipping
Build Your Kit
Add accessories to your kit to create a complete solution.
Connect Single Link 6G-SDI to the newest HDMI 4K projectors and televisions that support Ultra HD over a single HDMI link. Lets you build Ultra HD monitoring with ease, while still working with all your regular SD and HD equipment!
Easy To Use Features
Broadcast, post production and professional AV environments are built using SDI equipment and cabling. It’s essential when converting to and from SDI that you maintain the highest possible video and audio quality. Mini Converters are compact, affordable and...
- 1x Mini Converter SDI to HDMI 4K
- 1x Software CD
- 1x 12V universal power supply with international socket adapters
About the Blackmagic SDI to HDMI 4K
The Mini Converter SDI to HDMI 4K includes everything you need to convert from SD, HD, 3G and 6G-SDI video sources to HDMI in SD, HD and Ultra HD video formats. You can also de-embed SDI audio to HDMI, AES/EBU or balanced analog audio out. Imagine using big screen Ultra HD TV’s and projectors for broadcast monitoring! The built in down converter even allows Ultra HD monitoring on HD televisions!.
Connect Single Link 6G-SDI to the newest HDMI 4K projectors and televisions that support Ultra HD over a single HDMI link. Lets you build Ultra HD monitoring with ease, while still working with all your regular SD and HD equipment!
Easy To Use Features
Broadcast, post production and professional AV environments are built using SDI equipment and cabling. It’s essential when converting to and from SDI that you maintain the highest possible video and audio quality. Mini Converters are compact, affordable and easy-to-use. Settings can be changed quickly using built-in mini switches, and with a diagram showing pin settings printed on the back you never need to refer to a manual! Mini Converters use standard broadcast video and audio connections, so you get the convenience and cost savings of using your own cables!
Ultra HD and 6G-SDI Technology
Make the move to Ultra HD, the broadcast standard of the future, easy! Be prepared now by installing equipment that is fully compatible with all your SD and HD-SDI infrastructure, but will also switch over to Ultra HD via 6G-SDI when you need to run Ultra HD! This means you’re ready for the future and can build your system with full Ultra HD compatibility! Ultra HD features an incredible 4 times the resolution of regular 1080 HD video for a massive 3840 x 2160 frame size! Ultra HD is amazing! The advanced 6G-SDI design also means the new Blackmagic Mini Converters models perform better when used in SD and HD formats than simple HD only converters!
Blackmagic Converters 7.1 Firmware now available
This software update adds Level A support to Mini Converter Optical Fiber 4K, as well as general performance improvements for all Mini Converters.
What's new in Converter Utility 7.1 -Level A support for Mini Converter Optical Fiber 4K
-General performance and stability improvements.
For more information and dowload, please visit the Blackmagic firmware download page (opens in a new window).
| Connections | |
| SDI Video Input | 1 x SD, HD or 6G-SDI. |
| SDI Video Output | (4K HDMI output only) |
| HDMI | HDMI type A out. |
| SDI Redundant Input | Automatically switches over if main SDI input is lost. |
| Multi Rate Support | Auto detection of SD, HD or 6G-SDI |
| Updates and Configuration | Via USB 2.0 high speed. (480 Mb/s) |
| Reclocking | Yes |
| Standards | |
| SD Format Support | 525/29.97 NTSC, 525/23.98 NTSC, 625/25 PAL |
| SDI Compliance | SMPTE 292M,SMPTE 259M,SMPTE 296M,SMPTE 372M,SMPTE 424M and SMPTE 425M. |
| SDI Auto Switching | Automatically detects SD, HD or 6G-SDI. |
| HD Format Support | 720p59.94 |
| . | 720p60 |
| . | 1080i50 |
| . | 1080i59.94 |
| . | 1080i60 |
| . | 1080PsF23.98 |
| . | 1080PsF24 |
| . | 1080PsF25 |
| . | 1080PsF29.97 |
| . | 1080PsF30 |
| . | 1080p23.98 |
| . | 1080p24 |
| . | 1080p25 |
| . | 1080p29.97 |
| . | 1080p30 |
| . | 1080p50 |
| . | 1080p59.94 |
| . | 1080p60 |
| SDI Video Rates | SDI video connections are switchable between standard definition,high definition and 6G-SDI. |
| SDI Video Sampling | 4:2:2 and 4:4:4 |
| HDMI Format Support | 625/25 PAL |
| . | 525/29.97 NTSC |
| . | 525/23.98 NTSC |
| . | 720p50 |
| . | 720p59.94 |
| . | 720p60 |
| . | 1080i50 |
| . | 1080i59.94 |
| . | 1080i60 |
| . | 1080p23.98 |
| . | 1080p24 |
| . | 1080p25 |
| . | 1080p29.97 |
| . | 1080p30 |
| . | 1080p50 |
| . | 1080p59.94 |
| . | 1080p60 |
| . | 2048x1080p23.98 |
| . | 2048x1080p24 |
| . | 2048x1080p25 |
| . | 3840x2160p23.98 |
| . | 3840x2160p24 |
| . | 3840x2160p25 |
| . | 3840x2160p29.97 |
| . | 3840x2160p30 |
| . | 4096x2160p24 |
| 2K Format Support | 2048x1080PsF23.98 |
| . | 2048x1080p23.98 |
| . | 2048x1080PsF24 |
| . | 2048x1080p24 |
| . | 2048x1080PsF25 |
| . | 2048x1080p25 |
| SDI Audio Sampling | Television standard sample rate of 48 kHz and 24 bit. |
| 4K Format Support | 3840x2160p23.98 |
| . | 3840x2160p24 |
| . | 3840x2160p25 |
| . | 3840x2160p29.97 |
| . | 3840x2160p30 |
| . | 4096x2160p24 |
| SDI Color Precision | 4:2:2 and 4:4:4 |
| SDI Color Space | YUV and RGB |
| HDMI Color Space | YUV and RGB |
| HDMI Color Precision | 4:2:2 and 4:4:4 |
| Software | |
| Software Control | Mac OS X™ and Windows™ software upgrade via USB. |
| Internal Software Upgrade | Via included updater application. |
| Settings Control | Mini Switches or USB software. |
| Power Requirements | |
| Power Supply | +12V universal power supply included with international socket adapters for all countries. Cable tie point. |
| Power Consumption | 5.2 Watts |
| Operational Voltage Range | 12 - 30 V DC |
| Physical Specifications | W x H x D (92.27mm x 23mm x 114.25mm) |
| Environmental Specifications | |
| Operating Temperature | 0° to 40° C (32° to 104° F) |
| Storage Temperature | -20° to 45° C (-4° to 113° F) |
| Relative Humidity | 0% to 90% non-condensing |
Standard AudioConnections
Mini Converters support embedded SDI and HDMI audio and several models let you separately embed or de-embed analog or digital audio. Mini Converters support 24 bit analog and AES/EBU audio and use standard 1/4" audio jacks so you don't need custom cables!
Powerful Performance
Unlike other converters that can be confusing to operate and sometimes identify, Mini Converters combine powerful performance with a simple, compact design! Built-in connections are easy to access and all use standard cables that you're already likely to own!
Optical Fiber Conversion
Mini Converter is available in a 6G-SDI to optical fiber model. You get bi-directional 6G-SDI to optical fiber conversion, with each direction independent of each other. Optical fiber cables span distances up to 28 miles without any deterioration to the signal.
Highest Quality Processing
With the highest quality video processing, Mini Converters are ideal for all broadcast, post production and professional AV applications. Multiple internal power supplies ensure incredibly low noise levels when moving between analog and digital video formats. Specific models include up/down/cross conversion that lets you move easily between PAL and NTSC SD video standards and the high number of HD formats in up to 3840 x 2160 Ultra HD resolutions.
Easy Settings Control
Changing Mini Converter's built-in mini switch settings is as easy as using a pen! This is great when you need to change settings quickly as there are no complicated menus to navigate! You can also control settings using the included Converter Utility software.Connect a Mini Converter to any Mac OS X or Windows based laptop or desktop computer! All models can be updated via USB 2.0 by simply downloading software upgrades directly from the Blackmagic Design website.
